Why Every Clinician Needs a Reliable Hemostat The Definitive Guide for Surgical Success, Patient Safety, and Clinical Confidence.

In short: a haemostat (also spelled hemostat, and often called artery forceps or haemostatic forceps) is a ring-handled forceps with a ratchet lock, used to clamp a blood vessel or hold tissue. Patterns differ mainly in length, jaw length, how much of the jaw is serrated, whether the tip has teeth, and whether the jaws are straight or curved. The patterns most often asked for are mosquito (Halsted and Hartmann), Kelly, Crile, Pean, Spencer Wells and Kocher.

This guide is the starting point for our haemostat and artery forceps articles. Each section links to a more detailed guide.

Clinician holding a haemostat in an operating theatre

What a haemostat is

A haemostat closes like a pair of scissors, but instead of blades it has two jaws that grip. A ratchet between the ring handles holds the jaws closed at the chosen pressure, so the instrument stays clamped without being held. For a plain-language explanation, see what a haemostat is and how it works. If the names confuse you, see haemostat vs mosquito forceps vs artery forceps.

Parts of a haemostat

  • Jaws: the gripping end, usually with horizontal serrations. Some patterns have 1Ă—2 teeth at the tip.
  • Box lock: the joint where one half passes through the other.
  • Shanks: the arms between the joint and the rings. Their length sets the reach.
  • Ratchet: the interlocking steps that hold the jaws closed.
  • Finger rings: the handles.

Main haemostat patterns

The table lists the patterns and sizes shown on our Forceps and Clamps pages. Most are listed in straight and curved versions.

Pattern Jaws Lengths listed Read more
Baby mosquito (Hartmann) Fine; serrated or 1Ă—2 teeth 100 mm Baby mosquito forceps guide
Mosquito (Halsted) Fine; serrated or 1Ă—2 teeth 125 mm; longer patterns of 185 mm and 200 mm Mosquito artery forceps guide
Kelly Serrated over about half the jaw 140 mm Kelly forceps guide
Crile Serrated along the full jaw; serrated or 1Ă—2 teeth 140 mm and 160 mm Crile artery forceps guide
Pean and Rochester-Pean Serrated 125 mm to 280 mm Rochester-Pean haemostatic forceps
Spencer Wells Serrated 130 mm to 200 mm Spencer Wells haemostatic forceps
Kocher and Kocher-Ochsner Serrated with 1Ă—2 teeth 130 mm to 200 mm Kocher haemostatic forceps

Straight or curved

Straight jaws are generally chosen for work near the surface. Curved jaws keep the tips in view and reach around structures in a deeper field. See straight vs curved artery forceps.

Serrated or toothed

Serrated jaws grip across the whole clamped area. A 1Ă—2-toothed tip adds a firmer hold on tissue that will be removed. Several patterns on our site, including mosquito and Crile, are listed in both versions.

Which pattern for which job

Small, fine patterns such as mosquito forceps are for small vessels and delicate tissue. Larger patterns such as Kelly, Crile and Pean are for larger vessels and heavier tissue. See what haemostatic forceps are used for for a task-by-task summary.

Haemostats and other clamps

Haemostats are one family of surgical clamps. Towel clamps, intestinal clamps and vascular clamps do different jobs; see surgical clamps: types and uses. Vessels that must be preserved are held with atraumatic clamps rather than serrated haemostats; see haemostatic clamps vs atraumatic vascular clamps.

Video: mosquito artery forceps

Care

The box lock, ratchet and serrations are the areas that trap soil and show wear first. See how to clean and maintain artery forceps.

Frequently asked questions

Are a haemostat and artery forceps the same thing?

In everyday use, yes. Haemostat, hemostat, haemostatic forceps and artery forceps are different names for the same family of locking, ring-handled forceps.

What is the smallest haemostat?

Among the common patterns, the baby mosquito (Hartmann) forceps is the smallest; it is listed on our site at 100 mm. The Halsted mosquito forceps is listed at 125 mm.

What is the difference between Kelly and Crile forceps?

They are similar in size. On our product pages, Kelly forceps are described as serrated over about half of the jaw, and Crile forceps as serrated along the full length of the jaw.
